TUALAJ 8300 ANTI-JAM

CRPA SYSTEM


GPS L1, Glonass L1, Galileo, Beidou 운영

TUALAJ 8300은 별도의 항재밍 채널을 통해 여러 GNSS 위성군을 동시에 지원합니다. 각 채널의 넓은 대역폭은 GNSS 수신기가 M 코드와 SBAS 신호를 처리할 수 있도록 합니다.


50dB 재밍 억제

TUALAJ 8200은 강력한 디지털 빔포밍 알고리즘을 통해 어떤 방향에서도 50 dB의 광대역 재밍 억제를 수행할 수 있습니다.

특징

Immediate availability for urgent operational needs

Simple assembly means easy to install or retrofit

Compatible with all types of external GPS receivers and vehicle navigation systems

Minimal integration training required

Light Weight

Ultra Compact Size

Superior Suppression Performance

Embedded GNSS Receiver Option

Integrates easily into new or legacy platforms

Assured PNT

규격

Dimensions (cm)
7 x 13.9 x 2.1
Weight (g)
380
Power
Consumption (w)
< 24 W
Antenna Array
8 Array CRPA Antenna
Simultaneous
Independent
Nulling
7
Simultaneous
Active Bands
GPS L1,
GPS L2 GLONASS G1,
GLONASS G2,
GALILEO E1,
BEIDOU B1C SBAS

Nominal
Wideband
Suppression
>50 dB
Data Interfaces
Serial
Bandwidth
Up to 30 Mhz (depends to selected band option)
Connectors
9x MCX Female,
Micro-D 25-pin Socket

Operating
Voltage
12-32 Vdc
Internal
GNSS
Receiver
BeiDou (B1C),
Galileo (E1,E5a),
SBAS GLONASS (L1,L2),
GPS (L1,L2),
QZSS (L1)

Internal
GNSS
Tracking
Sensitivity
-164 dBm
RTCM Support
Yes
Environmental
Tests
MIL-STD-810G
EMI / EMC
MIL-STD-461F
Operating
Temperature
-40 °C to +85 °C

GPS L1, Glonass L1, Galileo, Beidou 운영

TUALAJ 8300은 별도의 항재밍 채널을 통해 여러 GNSS 위성군을 동시에 지원합니다. 각 채널의 넓은 대역폭은 GNSS 수신기가 M 코드와 SBAS 신호를 처리할 수 있도록 합니다.


50dB 재밍 억제

TUALAJ 8200은 강력한 디지털 빔포밍 알고리즘을 통해 어떤 방향에서도 50 dB의 광대역 재밍 억제를 수행할 수 있습니다.

TUALAJ 8300 ANTI-JAM

CRPA SYSTEM


특징

Immediate availability for urgent operational needs

Simple assembly means easy to install or retrofit

Compatible with all types of external GPS receivers and vehicle navigation systems

Minimal integration training required

Light Weight

Ultra Compact Size

Superior Suppression Performance

Embedded GNSS Receiver Option

Integrates easily into new or legacy platforms

Assured PNT

규격

Dimensions (cm)
7 x 13.9 x 2.1
Weight (g)
380
Power Consumption (w)
< 24 W
Antenna Array
8 Array CRPA Antenna
Simultaneous Independent Nulling
7
Simultaneous Active Bands
GPS L1,
GPS L2 GLONASS G1,
GLONASS G2,
GALILEO E1,
BEIDOU B1C SBAS

Nominal Wideband Suppression
>50 dB
Data Interfaces
Serial
Bandwidth
Up to 30 Mhz (depends to selected band option)
Connectors
9x MCX Female,
Micro-D 25-pin Socket

Operating Voltage
12-32 Vdc
Internal GNSS Receiver
BeiDou (B1C),
Galileo (E1,E5a),
SBAS GLONASS (L1,L2),
GPS (L1,L2),
QZSS (L1)

Internal GNSS Tracking Sensitivity
-164 dBm
RTCM Support
Yes
Environmental Tests
MIL-STD-810G
EMI / EMC
MIL-STD-461F
Operating Temperature
-40 °C to +85 °C
